APlusLift AP-14SR 2-Post Overhead Car Lift Single Release Direct Drive 6350 kg

APlusLift AP-14SR 2-Post Overhead Car Lift Single Release Direct Drive 6350 kg

Name: APlusLift AP-14SR 2-Post Overhead Car Lift Single Release Direct Drive 6350 kg
Brand: APlusLift
Price: 2997.0 USD
Availability: InStock

$2,997.00 - $2,997.00

$2,997.00

$2,997.00 - $2,997.00

$2,997.00

FREE Shipping to all locations in USA

Delivered in 8 to 12 business days

The APlusLift AP-14SR is a 6350 kg capacity 2-post overhead car lift designed for reliable performance in professional garages. Its robust all robot-welded steel frame with powder-coated finish and direct drive dual hydraulic cylinders ensures smooth, safe lifting. CE-certified hydraulic system is tested for 115% dynamic and 150% static load capacity.

Equipped with a single point safety lock release and automatic arm restraints, this lift offers effortless operation. It includes two sets of truck adapters, adjustable drop-in pads, anchor bolts, and shims. Backed by an industry-leading 3-year warranty, all replacement parts are readily available.

Key Features

Model	AP-14SR
Style	Overhead
Lock Release	Single Point Release
Warranty	3 Years (36 Months)
Lifting Capacity	6350 kg
Overall Height	420.0 cm
Overall Width	361.0 cm
Maximum Lift Height with Truck Adapters	202.2 cm
Maximum Lift Height without Truck Adapters	188.2 cm
Minimum Height of Adjustable Pads from Ground	17.0 cm
Drive Through Width (Carriage to Carriage)	264.5 cm
Column to Column Width	291.3 cm
Column Cross Section (L x W)	31.0 cm x 25.0 cm
Driving Mode	Dual hydraulic cylinders, direct drive
Motor	220V Single Phase 2.2 kW (30A breaker recommended)
Hydraulic Oil	12.1-18.9 liters AW32/AW46 (Not Included)
Time to Full Rise	75 seconds
Shipping Weight	1043 kg
Shipping Package Size (L x W x H)	381.0 cm x 83.8 cm x 53.3 cm
Arm Assembly	Symmetrical Arm Assembly
Front Arm Reach	81.7 cm to 125.0 cm
Rear Arm Reach	81.7 cm to 125.0 cm
Column Steel Thickness	6.4 mm
Carriage Steel Thickness	6.4 mm
Carriage Yoke Thickness	10.3 mm
Arm Steel Thickness	7.9 mm
Base Plate Steel Thickness	15.9 mm
Truck Adapters (Height Extensions)	Two sets: 4 x 14.0 cm tall, 4 x 7.0 cm tall
Other Parts Included	4 adjustable drop-in pads, 10 anchor bolts, 10 shims
Concrete Requirement	15.2 cm thick at 3500 psi reinforced with fiberglass or steel
Certification	CE Certified – Tested for 115% dynamic and 150% static load capacity

Highlights

3-year manufacturer's warranty against defects
Single Point Safety Lock Release System
Two sets of 2 3/4" tall and 5 1/2" tall truck adapters included; 6'7" maximum lift height with truck adapters
CE certified lift structure and hydraulic system; tested for 115% dynamic load capacity and 150% static load capacity
Robot-welded structure with durable powder-coated finish

How to use

To operate, press the 'UP' button on the motor to raise the lift. Lower it manually by pressing the release lever. The single point safety lock release ensures easy operation.

Downloads

AP-14SR Manual

Frequently asked questions

What is the lifting capacity of the AP-14SR?

The lifting capacity is 6350 kg.

What warranty is included?

It comes with a comprehensive 3-year warranty covering all parts.

What are the power requirements?

It requires a 220V single-phase supply with a 30A breaker; the motor is rated at 2.2 kW.

What is included in the package?

The package includes the lift assembly, two sets of truck adapters (four 7.0 cm tall, four 14.0 cm tall), four adjustable drop-in pads, ten anchor bolts, and ten shims.

Shipping information

Estimated delivery: 8–12 business days after order confirmation, contiguous U.S. only. Machines ship by tracked freight carrier — you’ll receive tracking details by email as soon as your order is dispatched.

Returns & warranty

All products includes a 2-Year Limited Warranty covering defects in materials and workmanship under normal use.
